General Information

---

Manufacturer: TRENDnet
Manufacturer Part Number: TEGS562
Brand Name: TRENDnet
Product Model: TEG-S562
Product Name: 6-Port Unmanaged Multi-Gig Switch
Marketing Information: Expand your network's bandwidth and reduce traffic bottlenecks with TRENDnet's Unmanaged Multi-Gigabit Switches. This 2.5G switch with SFP+ support comes equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. The 2.5G switch with 10G fiber also offers two dedicated 10G SFP+ ports for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The fanless design lowers energy consumption and eliminates distracting operating noise. TRENDnet's reliable multi-gigabit switches are cost-effective solutions to increase your network's throughput.

• DEVICE INTERFACE: 4 x 2.5G ports (100Mbps/1Gbps/2.5Gbps); 2 x 10G SFP+ ports (1Gbps/10Gbps); LED Indicators
• LIFETIME PROTECTION: We stand by the quality of our products. TRENDnet LIFETIME PROTECTION: The TEG-S562 multi-gig switch comes with Lifetime TRENDnet Manufacturer Protection.
• NDAA + TAA COMPLIANT: With our NDAA and TAA compliant network switches, you can plan and install networking solutions that Government customers demand today (U.S. and Canada Only)
• 2.5G PORTS: This 6 Port Multi-Gig Ethernet switch is equipped with four 2.5GBASE-T RJ-45 ports that provide multi-gigabitspeeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
• 10G SFP+ PORTS: The unmanaged switch offers two 10G SFP+ ports for high-speed network connections providing a cost effective solution in adding 10G link capability.
• FANLESS DESIGN: The compact fanless design of the 2.5G network switch lowers energy consumption costs and eliminatesoperating noise

• SWITCHING CAPACITY: 60Gbps switching capacity; EASY INSTALLATION: No configuration needed, simply connect network devices to the 2.5G Ethernet switch
• COMPLIANCE: IEEE 802.3bz (2.5G) compliant and IEEE 802.3ae (SFP+) compliant
• WALL MOUNTABLE: Features a convenient wall mountable design for greater installation flexibility; COMPATABILITY: Backwards compatible with 100/1000BASE-T devices

More from the Manufacturer

Product Type: Ethernet Switch

Technical Information

---

Features: Fanless

Interfaces/Ports

---

Total Number of Network Ports: 4
Network (RJ-45): Yes
Modular: Yes
Port/Expansion Slot Details:

4 x Gigabit Ethernet Network

2 x 10 Gigabit Ethernet Expansion Slot

Media & Performance

---

Media Type Supported:

Twisted Pair

Optical Fiber

Ethernet Technology:

2.5 Gigabit Ethernet

10 Gigabit Ethernet

Network Technology:

2.5GBase-T

10GBase-X

I/O Expansions

---

Total Number of Expansion Slots: 2
Expansion Slot Type: SFP+
Number of SFP+ Slots: 2

Network & Communication

---

Layer Supported: 2
Networking Standards:

IEEE 802.3bz

IEEE 802.3ae

IEEE 802.3ab

IEEE 802.3an

IEEE 802.1x

Management & Protocols

---

Manageable: No

Power Description

---

Input Voltage:

120 V AC

230 V AC

Power Source: Power Adapter
Power Consumption: 5.86 W

Physical Characteristics

---

Product Material: Metal
Form Factor: Wall Mountable
Height: 1" (25.40 mm)
Width: 6.20" (157.48 mm)
Depth: 4.30" (109.22 mm)
Weight (Approximate): 1 lb (453.59 g)

Miscellaneous

---

Package Contents:

• 6-Port Unmanaged Multi-Gig Switch
• Quick Installation Guide
• Power Adapter (12V, 1A)

Country of Origin: Taiwan
TAA Compliant: Yes

Warranty

---

Limited Warranty: Lifetime
