Description:
General Information
Manufacturer: ASUS Computer International
Manufacturer Part Number: PA32USD
Brand Name: Asus
Product Line: ProArt
Product Model: PA32USD
Product Name: ProArt PA32USD Widescreen OLED Monitor
Marketing Information:
ASUS ProArt Display OLED PA32USD Professional Monitor - 32-inch (31.5-inch viewable), 4K UHD (3840 x 2160), QD-OLED, 99% DCI-P3, E < 1, 240Hz, Self / Auto Calibration, HDR-10, HLG, Dolby Vision, Dual 12G-SDI, HDMI2.1, DisplayPort2.1, Thunderbolt™ 4 PD 96W, Calman Ready, ColourSpace Integration
- 31.5-inch 4K UHD (3840 x 2160) QD-OLED panel with 240 Hz refresh rate and 0.1 ms (GTG) response time for smooth rendering
- 1000 nits peak brightness with VESA DisplayHDR™ True Black 400 for exceptional color contrast
- True 10-bit color depth provides 100% sRGB, 99% DCI-P3 and BT. 2020 wide color gamut
- Dual 12G-SDI supports 4K@60Hz real-time playback without any compression, compatible with 6G and 3G Level A & B
- World-leading ∆E < 1 color performance and ASUS ProArt Hardware Calibration Technology for color-accuracy optimization and color profile write-back
- Multiple HDR format support, including Dolby Vision®, HLG and HDR10
- Rich connectivity including dual 12G-SDI, dual Thunderbolt™ 4 up to 96W Power Delivery, HDMI2.1, DisplayPort2.1 and a built-in USB Hub
- Includes two versatile stand options to suit any scenario or setup, along with an elegant metal handle for portability
- Monitor hood helps reduce reflections, and bundled clips allow for easy cable management
Stunning Contrast from Production to Post
Designed for content creators, the ProArt Display OLED PA32USD is a professional monitor that features a cutting-edge 31.5-inch 4K HDR QD-OLED panel with 1000-nits brightness and 99% DCI-P3 coverage to deliver highly-accurate colors and exceptional visual detail. A built-in motorized flip colorimeter enables auto- and self-calibration for consistent, professional-grade color accuracy, and a 240Hz refresh rate allows creators to work on color-critical artwork as well as performance-driven game development - all on one monitor. In addition to the standard I/O interfaces, the PA32USD supports dual 12G-SDI connectivity to receive uncompressed video signals up to 4K@60Hz.
True Professional-Grade Colors
The studio-grade 99% DCI-P3 gamut ensures richer, more vivid colors, making it the ideal monitor for both color-intensive projects and other creative pursuits.
Ultra-Accurate Color
ProArt displays are factory calibrated to guarantee industry-leading color accuracy. Each monitor undergoes stringent testing to ensure smooth color gradation.
Deeper Blacks, Brighter Whites
A peak brightness of 1000 nits (3% area) allows for outstanding contrast between the deepest black and gleaming white hues.
Advanced Panel Design
A graphene film behind the QD-OLED panel helps reduce operating temperature. Graphene is the thinnest and strongest nanomaterial in the world and has high thermal conductivity to help effectively dissipate heat.
Product Type: OLED Monitor
Technical Information
Number of Screens: 1
Screen Size Class: 32"
Viewable Screen Size: 31.5"
Screen Mode: 4K UHD
Panel Technology: Quantum Dot OLED
Response Time: 0.10 ms
Response Time Details: 0.1 ms GTG
Aspect Ratio: 16:9
Pixel Pitch: 0.18200 mm x 0.18200 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Mount Type: Wall Mountable
HDCP Supported: Yes
Features: Anti-reflectivesRGBHybrid Log Gamma (HLG)HDR10Flicker-freeScreen SaverDolby VisionDICOM CompliantColor Temperature SelectionHardware CalibrationProArt PaletteQuickFit PlusPicture by PicturePicture in PictureDisplayWidget CenterLow Blue LightMultiple HDR ModeKVMAmbient Light SensorProximity SensorKensington LockCalman ReadyVESA DisplayHDR True Black 400Wide Color Gamut (sRGB)Cable ManagementErgonomic DesignHorizontal Frequency: 15 kHz to 583 kHz - HDMI15 kHz to 583 kHz - DisplayPort15 kHz to 583 kHz - USB Type CVertical Frequency: 48 Hz to 240 Hz - DisplayPort48 Hz to 240 Hz - HDMI48 Hz to 240 Hz - Thunderbolt 448 Hz to 240 Hz - USB Type CAdjustable Stand: Yes
Stand Adjustments: SwivelHeightPivotTiltActive Display Area (H x V): 27.54" (699.40 mm) x 15.54" (394.70 mm)
Video
Maximum Resolution: 3840 x 2160
Standard Refresh Rate: 240 Hz
Color Supported: 1073.7 Million Colors (10-bit)
Dynamic Contrast Ratio: 1,500,000:1
Brightness: 250 cd/m²
Tearing Prevention Technology: VESA Adaptive Sync
Color Gamut: 100% sRGB99% DCI-P3Pixel Per Inch (PPI): 140
Brightness (Peak): 1000 cd/m²
Audio
Number of Speakers: 2
Speakers: Yes
Interfaces/Ports
HDMI: Yes
USB: Yes
DisplayPort: Yes
Thunderbolt: Yes
USB Type-C: Yes
Total Number of HDMI Ports: 1
Number of DisplayPorts: 1
Number of USB Ports: 4
Total Number of USB Type-C Ports: 2
Thunderbolt 4: Yes
Number of HDMI 2.1 Ports: 1
Built-in Devices
Built-in Devices: KVM SwitchUSB HubColorimeterPhysical Characteristics
VESA Mount Compatible: Yes
Height: 440.10 mm
Width: 718.30 mm
Depth: 59.60 mm
Height with Stand: 24.24" (615.80 mm)
Width with Stand: 28.28" (718.30 mm)
Depth with Stand: 9.44" (239.70 mm)
Weight (Approximate): 14.42 lb (6540 g)
Weight with Stand (Approximate): 20.02 lb (9080 g)
Miscellaneous
Package Contents:
- ProArt PA32USD Widescreen OLED Monitor
- Warranty Card
- USB-C to A cable
- USB-C cable
- Thunderbolt 4 Cable
- Quick start guide
- Power cord
- Monitor hood
- Mini Stand
- L-shaped Screwdriver
- HDMI Ultra High Speed Cable
- Ergonomic Stand
- DisplayPort 2.1 (DP80) cable
- Color pre-calibration report
- Cable Clip
Energy Star: Yes
Environmentally Friendly: Yes
Environmental Certification: Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
Warranty
Limited Warranty: 36 Month
