Description:
General Information
Manufacturer: Sharp Electronics
Manufacturer Part Number: EP-CA22
Brand Name: Sharp
Product Model: EP-CA22
Product Name: 28.6" ePaper
Marketing Information:
Sharp's EP-CA22 ePaper is an always on 28.6" display for digital signage users. With as low as 0W power consumption, it creates remarkably brilliant images even in brightly lit environments. With a paper like view, wide viewing angle and no backlight its easy on your eyes. Updating content is easy using either the PC, USB-C thumbdrive, Wireless or Bluetooth connections.
Features
- Always-On- Display is viewable at all times creating vibrant images even without power.
- Low Power Consumption- As low as 0W power consumption from the panel creating zero carbon emissions.
- Visiblility- The displays ensure excellent visibility in both the brightest environments, as well as semi-outdoor settings.
- Paper-Like- Reflective display with no backlight and 180° wide viewing angle provide paper like viewing that is easy on the eyes.
- Easy to install- The thin lightweight design allows for easy and flexible installation. It also enables installation in locations that could not be achieved with existing displays.
- Flexible content provisioning- PC, USB-C thumbdrive, Bluetooth, and wireless LAN connectivity allow for multiple ways to transfer content from the source to the display.
- Controls- The Mode button offers the capability to switch between Manually or Automatically switching images. The Pairing button allows for connection to mobile devices to update content to the display.
Packaged Quantity: 1 / Pack
Product Type: Digital Signage Display
Technical Information
Panel Technology: ePaper
Display & Graphics
Number of Screens: 1
Viewable Screen Size: 28.60" (726.44 mm)
Screen Size Class: 29" (736.60 mm)
Display Screen Type: LCD
Display Resolution: 5783 x 8192
Orientation: Face-up/Landscape/Portrait/Face-down
Aspect Ratio: 1.4:1
Network & Communication
Ethernet: Yes
Wireless LAN: Yes
Bluetooth: Yes
Interfaces/Ports
USB: Yes
Power Description
Input Voltage: 9 V DC
Physical Characteristics
VESA Mount Standard: 200 x 200
Height: 17.24" (438 mm)
Width: 24.33" (618 mm)
Depth: 0.58" (14.70 mm)
Weight (Approximate): 5.07 lb (2300 g)
Environmental Conditions
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 122°F (50°C)
Minimum Storage Temperature: 68°F (20°C)
Maximum Storage Temperature: 140°F (60°C)
Minimum Operating Humidity: 20%
Maximum Operating Humidity: 80%
Minimum Storage Humidity: 10%
Maximum Storage Humidity: 80%
Miscellaneous
Package Contents:
- 28.6" ePaper
- Power Cord
- AC Adapter
- Operation Manual
- Warranty Card
Indoor/Outdoor: Outdoor
Country of Origin: China
Warranty
Limited Warranty: 3 Year
