Description:
General Information
Manufacturer: StarTech.com
Manufacturer Part Number: 132N-TB4USB4DOCK
Brand Name: StarTech.com
Product Name: Docking Station
Marketing Information: BTI APCRBC158-SLA158 RBC158 SEALED LEAD ACID FOR BACK-UPS PRO BX1000M, BACK-UPS PRO BX1000M-LM60, BACK-UPS PRO BX1000M-TW, BX1000M, BX1000M-TW, BX100M-LM60
Packaged Quantity: 1
Product Type: Docking Station
Technical Information
Connectivity Technology: Wired
Charging Capability: Yes
Number of Displays Supported: 4
Supported Resolutions: 3840 x 21607680 x 4320Screen Mode Supported: 8K4K @ 60HzMemory Card Reader: Yes
Management Features: PXE BootWake-on-LANMAC Address Pass-throughMemory Card Supported: microSDSDMicro Size MultiMediaCard (MMC)SDHCSDXCmicroSDHCmicroSDXCDevice Supported: SpeakerHeadsetMonitorTabletNotebookSmartphoneNetwork & Communication
Ethernet Technology: 2.5 Gigabit Ethernet
Interfaces/Ports
Host Interface: Thunderbolt 4
Total Number of USB Ports: 7
Number of USB 2.0 Ports: 1
Number of USB 3.2 Gen 1 Type-A Ports: 2
Number of USB 3.2 Gen 2 Type-A Ports: 3
Number of USB Type-C Ports: 1
USB Type-C: Yes
USB Type-C Detail: 1 x USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
Number of USB Type-A Ports: 6
USB Type-A: Yes
Number of RJ-45 Ports: 1
Network (RJ-45): Yes
Number of DisplayPort Outputs: 2
DisplayPort: Yes
DisplayPort Version: 1.4
Headphone/Microphone Combo Port: Yes
Number of HDMI Outputs: 2
HDMI: Yes
HDMI Version: 2.1
Thunderbolt: Yes
Thunderbolt Ports Quantity: 1
Number of Thunderbolt 4 Ports: 1
USB Power Delivery: 98W
Software
Operating System Supported: Windows 11Windows 10macOS Big SurmacOS MontereymacOS VenturamacOS SonomamacOS Sequoia 15Power Description
Maximum Power Supply Wattage: 180 W
Physical Characteristics
Product Color: Space Gray
Height: 1.40" (35.56 mm)
Width: 8.30" (210.82 mm)
Weight (Approximate): 7.10 oz (201.28 g)
Miscellaneous
Package Contents:
- Docking Station
- 1 x 3ft (1m) Thunderbolt 4 Host Cable
- 1 x Universal Power Adapter (North America)
- 1 x Quick-Start Guide
Kensington Security Slot: Yes
Compatibility:
Compatible Devices:
- Apple iPad Pros with M1 or later processors
- Intel Evo/Tiger Lake (11th gen & up) Thunderbolt 4 laptops
- Dell Precision 5560 Mobile Workstation
- Dell Precision 5760 Mobile Workstation
- Dell XPS 13 9310 2 in 1 Laptop
- HP EliteBook 850 G8 Notebook PC
- HP ProBook 450 G8 Notebook PC
- Lenovo X1 Carbon 9th Gen Laptop
- Apple M1/M2/M3 Pro/Max MacBooks
- Apple MacBook Air
- Apple iPad Pro M1
- All Thunderbolt 4/3 and USB4 laptops
Environmentally Friendly: Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)Waste Electrical and Electronic Equipment Directive (WEEE) Warranty
Limited Warranty: 3 Year
0 items
):
$378.95
