Description:
General Information
Manufacturer: Fortinet, Inc
Manufacturer Part Number: FAP-234G-A
Brand Name: Fortinet
Product Line: FortiAP
Product Model: 234G
Product Name: FortiAP 234G Wireless Access Point
Marketing Information:
This enterprise class Wi-Fi 6E ruggedized indoor/outdoor AP provides three radios with internal antennas and two spatial streams. This access point supports the 6 GHz band, OFDMA, a 2.5 Gigabit Ethernet port, plus an additional 1 Gbps Ethernet port for PoE diversity. The AP can provide 24/7 scanning across all bands while still providing access on both the 2.4 GHz and 5 GHz bands or 2.4 Ghz and dual 5 GHz service or the AP can be configured to provide simultaneous access on 2.4 GHz, 5 GHz, and the 6 GHz bands. The integrated BLE radio can be used for beacons and locationing applications.
Product Type: Wireless Access Point
Technical Information
Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax/e/i/r/k/v/w/u
Network Band: Tri Band
Frequency Band: 2.40 GHz5 GHz6 GHzTotal Number of Antennas: 8
Number of Internal Antennas: 8
Indoor/Outdoor: Indoor/Outdoor
Wireless Transmission Speed: 4.08 Gbit/s
MIMO Technology: Yes
MIMO Type: Multi User MIMO
Data Encryption: Yes
Encryption Standard: EAP-TLSEAP-TTLSPEAPv0PEAPv1MSCHAPv2EAP-GTCEAP-SIMEAP-AKAEAP-FASTWPAWPA2WPA3WEPIngress Protection (IP) Rating: IP67
AI-powered: Yes
Interfaces/Ports
Ethernet Technology: 2.5 Gigabit EthernetGigabit EthernetNumber of Network (RJ-45) Ports: 2
PoE PD Port: Yes
USB: Yes
Management Port: Yes
Network & Communication
Wi-Fi Generation: Wi-Fi 6E
Power Description
Power Consumption: 28 W
Physical Characteristics
Form Factor: Wall MountablePole-mountableDesktopAntenna Form Factor: Internal
Height: 2.26" (57.30 mm)
Width: 8.50" (216 mm)
Depth: 10.16" (258 mm)
Weight (Approximate): 3.05 lb (1383.46 g)
Miscellaneous
Package Contents:
- FortiAP 234G Wireless Access Point
- Wall and Pole Installation Brackets with Mounting Kits
- PoE Injector
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: Lifetime
