Description:
General Information
Manufacturer: Kingston Technology Company
Manufacturer Part Number: KF560C30BWEK2-32
Brand Name: Kingston
Product Line: FURY Beast
Product Name: FURY Beast 16GB (2 x 8GB) DDR5 SDRAM Memory Kit
Marketing Information:
Kingston FURY KF560C30BWEK2-32 is a kit of two 2G x 64-bit (16GB) DDR5-6000 CL30 SDRAM (Synchronous DRAM) 1Rx8, memory module, based on eight 2G x 8-bit FBGA components per module. Each module kit supports AMD® EXPO v1.1 and Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit capacity is 32GB. Each module has been tested to run at DDR5-6000 at a low latency timing of 30-36-36 at 1.4V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers.
Product Type: RAM Module
Technical Information
Memory Size: 16 GB
Memory Technology: DDR5 SDRAM
Memory Voltage: 1.40 V
Number of Modules: 2 x 8GB
Memory Speed: 6000 MHz
Memory Standard: DDR5-6000/PC5-48000
Memory Rank: Dual-rank
Error Checking: On-die ECC
CAS Latency: CL30
Physical Characteristics
Number of Pins: 288-pin
Form Factor: DIMM
Thickness: 0.26" (6.62 mm)
Width: 1.37" (34.90 mm)
Length: 5.25" (133.35 mm)
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: Hazard Assessment of Perfluorooctane Sulfonate (PFOS)
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)Restriction of Hazardous Substances (RoHS)Warranty
Limited Warranty: Lifetime
